• Encoding formats such as H.265, MPEG4, MPEG 2, MJPEG, etc
• 4-channel HDMI output
• PAL and NTSC
• 1080P, 720P, SVGA, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF resolution decoding
• G. 722, G.711A, G.711U, MPEG2-L2, ACC audio formats
• URL decoding
• VGA/HDMI High Definition
• ONVIF
• Screen splicing function
• Screen segmentation 4/9/16, camera selection and control
• Camera image polling
• Alarm linkage (switch signal)
• Audio output
• 100M/1000M Ethernet port
• TCP, UDP, RTP, MCAST protocols
• HTTP, DHCP, DDNS network functions
• Configure the decoder by accessing it through a browser or software client
• Can be remotely upgraded through the network to achieve remote maintenance
• HDMI 1.3 standard output
• Interface: HDMI-A socket, 19 pins, female head;
• Minimum and maximum voltage levels: T.D.M.S  2.9V/3.3V
• Impedance: 75 Ω
• Pixel bandwidth: 165MHz, all digital
• Interface bandwidth: 2.25Gbps, all digital
• Bit clock jitter:< 0.25Tbit（20%-80%）
• Rise time:< 0.3Tbit（20%-80%）
• Maximum transmission delay: 5ns (± 1ns)
• Output in formats such as 1920 × 1080P, 1920 × 1080I, 1280 × 720P, 1280 × 720I, and custom resolutions. Suggested maximum transmission distance: less than 20 meters at 1080P (recommended to use certified HDMI cable)

        Model：    VET-DLP8000-4        4 channel output

                         VET-DLP8000-8        8 channel output

                         VET-DLP8000-12     12 channel output

                         VET-DLP8000-16     16 channel output
